Gold CIP CIL Production Line Plant Equipment for Gold Beneficiation Plant

Cyanidation with carbon adsorption is the backbone of modern gold recovery, and the CIL and CIP processes are the most efficient ways to combine leaching and adsorption in one continuous circuit. In CIL, gold is leached and adsorbed onto activated carbon at the same time; in CIP, the two steps run in separate tanks.

The Gold CIP CIL Production Line Plant Equipment includes leaching and adsorption tanks fitted with inter tank screens and carbon transfer mechanisms, air or oxygen sparging, and a full carbon elution, electro winning and regeneration section. Slurry flows through the tanks while activated carbon moves counter current, collecting the dissolved gold before it is desorbed in the elution column.

The plant is designed for reliable, low cost operation with automatic carbon transfer and dense slurry handling. It suits both new gold mines and expansions of existing operations, and the whole line is delivered as modular tanks, columns and skid mounted units for rapid site assembly.

• High Gold Recovery: Counter current carbon movement and optimised leaching give a gold recovery above 90 percent from a wide range of ores.
• CIL And CIP Options: The plant can be configured as a combined leach and adsorption CIL circuit or as a separate leach then CIP circuit to suit the ore.
• Automatic Carbon Transfer: Air lift or pump transfer mechanisms move loaded carbon between tanks automatically, cutting labour and carbon loss.
• Complete Elution Circuit: Elution, electro winning and carbon regeneration sections recover the gold and return reactivated carbon to the adsorption tanks.
• Modular Construction: Tanks, columns and skids are prefabricated for container shipment and fast site assembly, shortening the construction schedule.
• Low Operating Cost: Efficient reagent use, oxygen sparging and heat recovery in the elution circuit keep the cost per ounce low.

The Gold CIP CIL Production Line Plant Equipment is used in gold mines, gold concentrators and tailings retreatment plants. It recovers gold from oxide and sulfide ores as well as from gravity tailings and flotation concentrates, and it is often combined with gravity separation and flotation circuits to form a complete gold beneficiation plant.

Tanks and columns are match marked and coated with anti rust primer before shipping, while pumps, agitators, carbon transfer gear and control panels are crated individually for container transport. Lined surfaces are protected against impact. Process flow diagrams, foundation drawings and commissioning support are provided, and the line carries a twelve month warranty against manufacturing defects.
